STP Root Bridge Configuration: Primary, Secondary and Priority
Learn how to choose the STP root per VLAN with Cisco IOS root primary, root secondary and manual bridge-priority commands.
STP root bridge configuration: key takeaways
spanning-tree vlan X root primary|secondary to let Cisco IOS select a lower priority, or use spanning-tree vlan X priority VALUE to set the bridge priority explicitly.- The switch with the lowest Bridge ID becomes root.
- Bridge priority wins first; the MAC address breaks an exact priority tie.
- Manual priority values range from 0 through 61440 in increments of 4096.
- With the extended system ID, the displayed priority equals the configured priority plus the VLAN ID.
- PVST can use a different root bridge for each VLAN.
- Place the primary and secondary roots on appropriate distribution or backbone switches—not randomly on access switches.
What the root bridge controls
Every spanning-tree instance builds its loop-free topology around one root bridge. Non-root switches select their lowest-cost path toward that root, which influences root ports, designated ports, blocked redundant paths and therefore the Layer 2 forwarding pattern.
How STP elects the root bridge
Switches compare Bridge IDs carried in BPDUs. The numerically lowest Bridge ID wins.
SW2 wins even though another switch might have a lower MAC address, because bridge priority is compared before MAC address. MAC address is only the tie-breaker when effective priorities match.
Extended system ID calculation
For VLAN 10, configured priority 24576 appears as 24586. For VLAN 20, configured priority 0 appears as 20. The VLAN ID is the extended system ID; it does not mean the configured base priority changed.
Prerequisites and lab topology
Before configuring the root bridge, understand PVST, root election, Bridge ID components, VLAN creation and 802.1Q trunks. The examples use three switches connected in a redundant triangle with VLANs 10, 20 and 30 carried across trunks.
SW1, SW2, SW3(config)# vlan 10 SW1, SW2, SW3(config)# vlan 20 SW1, SW2, SW3(config)# vlan 30 SW1, SW2, SW3(config)# interface range GigabitEthernet0/0 - 1 SW1, SW2, SW3(config-if-range)# switchport mode trunk
Step 1: verify the current root bridge
Never change STP priority blindly. First identify the current root and each switch’s own Bridge ID.
SW1# show spanning-tree vlan 10
VLAN0010
Root ID Priority 32778
Address 5254.0015.bc74
Cost 4
Port 1 (GigabitEthernet0/0)
Bridge ID Priority 32778 (priority 32768 sys-id-ext 10)
Address 5254.001a.935aIf the output says This bridge is the root, the local switch owns the Root ID. Otherwise, compare Root ID with Bridge ID and note the root-facing port.
SW1# show spanning-tree bridge detail SW1# show spanning-tree root SW1# show spanning-tree vlan 10 summary
Step 2: choose a configuration method
Method A: root primary / secondary
Use Cisco IOS convenience commands when you want the software to choose an appropriate priority relative to the current topology.
SW1(config)# spanning-tree vlan 10 root primary SW2(config)# spanning-tree vlan 10 root secondary
root primary attempts to make SW1 the current VLAN 10 root. root secondary lowers SW2’s priority so it is a strong backup candidate.
Method B: manual priority
Set an explicit, documented value when deterministic priority planning matters.
SW1(config)# spanning-tree vlan 10 priority 4096 SW2(config)# spanning-tree vlan 10 priority 8192
The lower number wins. Values must be multiples of 4096 from 0 through 61440.
Common priority values
Strongest409681922457632768
Default61440
The automatic value selected by root primary can depend on software, platform and current root priority. Many classic Catalyst PVST examples from a default topology produce 24576 for primary and 28672 for secondary, but you should confirm the actual running configuration instead of assuming those numbers universally.
Configure different roots per VLAN
PVST runs a separate spanning-tree instance for each VLAN. That means root placement can be divided across distribution switches to align the active Layer 2 paths with gateway placement and uplink capacity.
Secondary: SW2
Secondary: SW1
Secondary: SW2
SW1(config)# spanning-tree vlan 10,30 root primary SW1(config)# spanning-tree vlan 20 root secondary SW2(config)# spanning-tree vlan 20 root primary SW2(config)# spanning-tree vlan 10,30 root secondary
Step 3: verify the new root and backup
- Run
show spanning-tree vlan 10on the intended primary and confirm This bridge is the root. - Confirm Root ID priority and address match the intended switch.
- On non-root switches, verify the root port and expected path cost.
- Check the running configuration for the effective priority.
- Repeat for every VLAN in the design.
SW1# show spanning-tree vlan 10
VLAN0010
Root ID Priority 24586
Address 5254.001a.935a
This bridge is the root
Bridge ID Priority 24586 (priority 24576 sys-id-ext 10)
SW1# show running-config | include spanning-treeCommon root bridge configuration mistakes
- Leaving the election to MAC addresses: the oldest or least suitable switch can become root when all priorities remain default.
- Configuring an access switch as root: this can pull Layer 2 paths away from the intended distribution design.
- Assuming “secondary” is guaranteed: election still follows the lowest Bridge ID.
- Forgetting the VLAN ID in displayed priority: 24586 represents base priority 24576 plus VLAN 10.
- Using an invalid priority: extended-system-ID environments require increments of 4096.
- Changing timers casually: prefer validated defaults or documented platform guidance.
- Skipping post-change verification: always confirm the root, port roles and blocked path per VLAN.
Spanning Tree Root Bridge Frequently Asked Questions
How do I make a Cisco switch the STP root?
Use spanning-tree vlan VLAN-ID root primary, or configure a lower explicit value with spanning-tree vlan VLAN-ID priority VALUE. Verify the result afterward.
What is the default STP priority?
The default configurable priority is 32768. With the extended system ID, Cisco output displays the base priority plus the VLAN ID.
Is priority 0 always the root?
Priority 0 is the lowest configurable base priority, but if multiple switches use it for the same VLAN, the lowest MAC address breaks the tie.
What does root secondary actually do?
It configures a lower bridge priority intended to make the switch a strong backup root candidate. STP itself does not define a “secondary root” role.
Can a VLAN range use the same root command?
Yes. Cisco IOS accepts VLAN lists and ranges, subject to platform syntax—for example, spanning-tree vlan 10,20,30 root primary.
Should the STP root match the default gateway?
In many campus designs, aligning the STP root with the active first-hop gateway reduces unnecessary Layer 2 path stretch. The correct choice still depends on the topology and redundancy design.
Authoritative references
This lesson’s command behavior and design cautions were checked against Cisco’s official Spanning Tree Protocol guide and current Catalyst STP configuration guidance.
